Aluminum Sheet 3003 H14 Flexible Aluminum Sheet Roll
3003 aluminum alloy sheet is a typical Al-Mn alloy, with good
formability, very good corrosion resistance and weldability. It is
often used to make power battery shells in lightweight automobiles,
cookware, food storage devices, tanks and bins on transportation
equipment, metal sheet pressure vessels and pipes.
Our company can produce high-quality 3003 ultra-wide and
ultra-thick aluminum plates with internal stress relief and no
deformation during cutting. The maximum width is 2650mm and the
maximum thickness is 500mm. Welcome new and old customers to
consult and order.
Specifications:
| Aluminum | Aluminum Grade |
| STANDARD | ASTM B209,JIS H4000-2006,GB/T 3190-2008,GB/T 3880-2006,etc. |
| 1000 Series | 1050 1060 1070 1100 |
| 2000 Series | 2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17 |
| 3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 |
| 4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A |
| 5000 Series | 5052, 5083, 5754, 5005, 5086,5182 |
| 6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02 |
| 7000 Series | 7075,7050,7A04,7472,7475 |
| Thickness(mm) | 0.12-350 |
| Width(mm) | 50-2500mm |
| Length(mm) | in coil shape, or as requested. |
| Surface | Wire drawing,oxidation,PS,Mirror surface,Embossing etc |
| Temper | H111, H112, H116, H321, H12, H22, H32, H14, H24, H34, H16, H26,
H36, H18,,H28, H38, H114, H194, etc |
| Type | Coil, Sheet, Strips, Plate |
| Payment | L/C, T/T, D/P, West Union, etc. |
| Package | Standard export package,such as wooden box or as required. |
| Port | Tianjin, Qingdao,Shanghai |
Chemical Composition & Mechanical properties:
Sheet 1:
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | OTHERS | OTHERS | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | — | 0.05 | 0.03 | 0.03 | — | 99.5 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | — | 0.04 | 0.03 | 0.03 | — | 99.7 |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | — | — | 0.1 | — | 0.05 | 0.15 | 99 |
| 2024 | 0.5 | 0.5 | 3.8-4.9 | 0.30-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | — | — | 0.1 | — | 0.05 | 0.15 | Rem. |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | — | 0.25 | — | 0.05 | 0.15 | Rem. |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | Rem. |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | — | 0.05 | 0.15 | Rem. |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | — | 0.05 | 0.15 | Rem. |
| 5252 | 0.08 | 0.1 | 0.1 | 0.1 | 2.2-2.8 | — | 0.05 | — | 0.03 | 0.1 | Rem. |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | 0.05 | 0.15 | Rem. |
Packaging and Shipping:
Package:
Standard seaworthy package. Wooden pallets with plastics protection
for the coil and sheet, or to be packed as your requests.
Loading:
Total quantity from 0-50 tons, can be shipped by containers.
More than 50 tons, can be shipped by bulk vessel.
20 ft container: can load width below 2300mm, length 6000 max.
40 ft container: can load width below 2300mm, length below 12000mm.
Packaging can also be customized as your requests.
Product Details Display:
Applications:
Typical applications of ultra-wide 3003 aluminum plates: bus skins,
silos, antenna pot materials, wide curtain wall panels, wide roof
panels, etc.;
Typical uses of hot-rolled 3003 aluminum plate: power battery
shell, automobile heat shield, fuel tank, water tank, automobile
anti-skid plate, battery cover plate, automobile interior, signs,
cans, medical equipment, etc.;
3003 aluminum foil coil use: aluminum foil for honeycomb core,
electronic foil, honeycomb material, meal box material, container
foil, etc.
