Aluminum 8000 series aluminum foil strips for sale
Specifications:
| Product name | Aluminum strip |
| Alloy / Grade | 1000 series, 3000 series, 5000 series, 6000 series, 7000 series,
8000 series |
| Temper | 0-H112, T3-T8, T351-T851 |
| Thickness | 0.13-6.5mm |
| Width | 3-2600mm |
| Length | As per your requirements |
| Applications | Industry, decorations, building, packing, pressing etc.. |
| Surface treatment | Mill finish, coated, powder coated, anodized, polished mirror,
embossed etc.. |
| Tolerances | As per your requirements |
| Delivery time | 7-30 days after receiving deposit or Original LC. |
| MOQ | 500kgs |
| Loading port | Shanghai port, Qingdao port |
| Coil ID | As per your requirements. |
| Prices terms | FOB, CIF, CFR(CNF), EXW etc. |
| Payment terms | LC, TT, West Union etc. |
| Mechanical Property |
| ALUMINUM | Grade | Normal | Temper | Tensile Strength | Yield Strength | Elongation% | Brinell Hardness |
| ALLOY | Temper | N/mm² | N/mm² | Plate | Bar | HB |
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 |
| Al-Cu | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| (2XXX) | 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 |
| Al-Mn | 3003 | | O | 110 | 40 | 30 | 37 | 28 |
| (3XXX) | 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| (5XXX) | 5083 | O,H112,H | O | 290 | 145 | - | 20 | - |
| Al-Mg-Si | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| (6XXX) | 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 |
| Al-Zn-Mg | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| (7XXX) | 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 |
Why Choose Aluminum to produce transformer?
Using aluminum to produce electronic transformers can greatly reduce costs, such as toroidal transformers can be reduced by about 20%.
Electronic transformers are mainly composed of three types of
materials: iron core, enameled wire and insulating material.
According to the structure, the iron core can be divided into: EI
type, C type, R type, ring type.
Enameled wires mainly include copper, aluminum, and copper-clad
aluminum.
The internationally leading welding process enables tin
infiltration of aluminum to form a tin-aluminum alloy layer on the
surface of the aluminum to achieve contact between two metal atoms.
The welding is in an oxygen-free state, purely physical, and does
not use any paint remover and flux, which is environmentally
friendly. No pollution and no corrosion.
This welding technology and process are obviously better than
ordinary soldering iron tinning on the copper wire. It not only
successfully solves the difficulty of aluminum welding, but also
leaves no hidden dangers of false welding. The two major problems
that have long plagued the production of aluminum transformers are
solved.
The unit price of aluminum is significantly lower than the unit
price of copper. The weight of aluminum in the same volume is only about 33% of
the weight of copper. Obviously, aluminum transformers have obvious
cost advantages when the iron core window can accommodate all
aluminum wires.
We(Henan YOWO Industrial) have more than 10 years experiences of Aluminum sheet, Aluminum foil and Aluminum strip products. We
fully understand our customers' needs and requirements, and
strictly in accordance with international standards such as ASTM,
EN_AB, JIS, GB for the production of various grades of aluminum
products.
We make sure each piece of aluminum roll No Burrs, No Scratches of
Round Edge to fit for transformer winding.
Any size can be customized. No matter you need large quantity or
small quantity, or trial order, we'll all treat it seriously. Give
us one chance to be your reliable supplier in the near future!
